Beosound Shape
Beosound Shape: Modular wall-mounted speakers.
Beosound Shape delivers immersive sound, customisable design and built-in acoustic dampers for design-conscious music lovers. Modular speaker systems can grow with your needs.
Beosound Shape technical specifications
Sound
| Recommended room size | 20–100 m² |
|---|---|
| Speaker configuration | Per acoustic panel: 1 x ¾-inch tweeter, 1 x 5 ¼-inch woofer |
| Amplifier | Per amplifier: 8 x 80 W, Class D. Maximum number of speakers per amplifier: 4 |
| Frequency range | 30 – 22,000 Hz (in an 8-tile configuration) |
| Maximum sound pressure level (SPL) at 1 m | 105 dB (in an 8-tile configuration) |
| Bass performance | 89 dB (SPL) (in an 8-tile configuration) |
| Advanced sound features | Adaptive bass linearisation, thermal protection. |
Design
| Designer | Øivind Alexander Slaatto |
|---|---|
| Materials | Textile polymer. |
| Dimensions | 36.4 (W) x 32.0 (H) x 11.1 (D) cm (1 tile). Maximum number of amplifier tiles: 10. Maximum number of speaker tiles: 44. Acoustic damper tiles: unlimited. |
| Weight | Speaker module: 1.9 kg + 0.4 kg (textile cover). Amplifier module: 2.0 kg + 0.4 kg (textile cover). Damper module: 0.51 kg + 0.4 kg (textile cover). |
Power
| Power supply | 100–240 V, 50/60 Hz mains cable |
|---|
Connectivity
| Bluetooth version | Bluetooth 5.3 |
|---|---|
| Bluetooth codecs | Android: SBC; iOS: SBC, AAC. |
| Wi-Fi | Dual-band Wi-Fi (2.4 and 5 GHz), IEEE 802.11 b/g/a/n/ac/ax. |
| Streaming services | Apple AirPlay, Spotify Connect, Google Cast, TIDAL Connect, B&O Radio, Deezer, QPlay 2.0. |
| Beolink Multiroom | Connect multiple Bang & Olufsen speakers to expand your listening experience. |
| Physical connections | Speaker module: 1 x 4-wire speaker input. Amplifier module: 4 x 4-wire speaker outputs, 1 x optical input, 1 x Power Link (RJ45), 1 x Comm In (amplifier input), 1 x Comm Out (amplifier output), 1 x USB-B, 1 x power. Beoconnect Core: 1 x power, 1 x USB-C (Performance digital output), 1 x HDMI eARC (for TV integration), 1 x Ethernet, 1 x COMM (for Beosound Shape), 1 x Powerlink (stereo), 1 x line input. |
| Remote controls | Bang & Olufsen app, Beoremote One BT, Beoremote Halo. |
